AirKF 700
PNEUMATIC EDGE BEVELLING MACHINE
AirKF 700 Pneumatic Edge Beveling Machine delivers fast, precise, and consistent edge chamfering for steel fabrication, welding preparation, and industrial metalworking. Designed in Germany and manufactured in Japan, this high-performance pneumatic beveling machine creates adjustable chamfers from C2 to C7 with exceptional accuracy. Its powerful 900 W air motor, 10,000 rpm speed, and 360° swivel exhaust ensure maximum productivity, operator comfort, and clean working conditions. The integrated cooling system extends carbide insert life while improving machining efficiency.
The AirKF 700 features a height adjustment system, safety lever, and durable 3× 8-sided carbide inserts for long-lasting performance and lower operating costs. Air jets remove chips from the workpiece, preventing buildup and delivering smoother finishes. Suitable for heavy-duty fabrication shops, shipbuilding, structural steel, and manufacturing industries, this portable pneumatic chamfering machine offers reliable performance, excellent surface quality, and professional results for demanding industrial beveling applications.
-
Made in Japan -
Designed in Germany
-
Pneumatic Drive
-
C2–C7 Chamfer
-
10,000 rpm
-
Insert Cooling
-
Swivel Exhaust
-
Carbide Inserts
-
Height Adjustment
-
Safety Lever
-
Low Vibration
-
Lightweight Body
-
Precise Chamfering
-
Weld Preparation
-
Low Maintenance
-
Industrial Quality
Technical Specifications
-
CHAMFER WIDTH:
C2–C7 (5/64"–9/32") -
SPEED:
10,000 min⁻¹ -
MOTOR OUTPUT:
900 W (1.2 HP) -
WEIGHT:
3.95 kg (8.7 lbs) -
AIR CONSUMPTION:
16 l/sec -
AIR INLET SIZE:
1/4" BSP
Scope of Delivery
-
CARBIDE INSERT (QUANTITY)
SHM 70 (3×) -
MILLING HEAD
ZFR 700 -
ADJUSTMENT TOOL
-
ALLEN KEY
3 mm -
T-WRENCH
4 mm -
GUIDE ROLLER
-
OPERATING INSTRUCTIONS
