Ø 40 mm Core Drilling & M16 Tapping
PipeMAB 525
STRONG GRIP ON PIPES & CURVED SURFACES
Pipe Drilling + Tapping Machine With Special Magnetic System
- Ideal for drilling+tapping on curved & flat surfaces
- Reversible motor with variable speed & torque controls
- Patented shallow-field magnetic technology
- Suitable for pipes 75 mm (3'') or larger
- Made in Germany lightweight and compact machine
- Strong grip for material as thin as 3 mm (9/64")
- Elongated tool holder for maximum utilization of the machines' stroke
Powerful magnetic adhesion force up to max. 1020kg (20 mm material thickness / S 275 JR). The new PipeMAB magnetic core drilling machines from BDS Maschinen, Made in Germany. The patented pipe magnetic clamping system with two permanent magnets automatically adapts to the pipe diameter. The swivel arrangement of the permanent magnets allows pivoting to conform to any pipe 85 mm (3") diameter or larger, on straight surfaces as well as inside and outside of the curve surfaces. Result: Fast, accurate and safe drilling with the BDS PipeMAB series.
Core Drilling
50 mm
Thread Cutting
M 20
Powerful Motor
1600 Watt
Weight
19.5 Kg
 Motor output |
Watt
|
1600 |
 Voltage, V AC |
Volt
|
230 - 110/125 |
 Core drill cutting depth max. |
mm
|
40 |
 Core drill max. Ø HSS/TCT |
mm
|
50 |
 Twist drill |
≤ Ø mm
|
20 |
 Reaming |
≤ Ø mm
|
20 |
 Countersinking |
≤ Ø mm
|
50 |
 Thread cutting |
≤ Ø mm
|
20 |
 Stroke |
mm
|
160 |
 Magnet dimensions |
mm
|
191 x 266 x 88 |
 Weight |
kg
|
19.5 |
 Spindle taper |
MT 3 |
|
 Arbor |
--- |
|
 KEYLESS 19 mm Weldon 3/4“ |
||
 Speed gears |
2 |
|
 Gear 1 range |
min-1
|
70 – 280 |
|
Gear 2 range |
min-1
|
180-580 |
 Permanent internal lubrication |
||
 Safety clutch |
--- |
|
 Torque control |
||
 Full-wave control electronics |
||
 Magnetic Indicator |
||
 Overheating protection |
||
 Carbon brush wear control |
Industrial arbor ZIAL 319 KN
1 Ejector pin ZAK 100
1 Hard-top case
1 Safety lashing strap
1 Taper drift MT 3/B16
1 Operating instructions
Product Video of Magnetic Drill Press
MAB 485 SB
Equipped With Swivel Base, Ø 40 mm Core Drilling & M16 Tapping
MAB 525
Ø 50 mm Core Drilling & M20 Tapping
MAB 525 SB
Equipped with Swivel Base, Ø 50 mm Core Drilling & M20 Tapping
MAB 455
Ø 40 X 55 mm Core Drilling
PipeMAB 200
Ø 35 mm Pipe Drilling Machine
PipeMAB 525
Ø 50 mm Pipe Drilling+Tapping Machine
MAB 455 SB
Swivel Base Equipped Ø 40 X 55 mm Core Drilling
MABasic 200
Ø 32 X 55 mm Core Drilling
MAB 825 KTS
Portable Drilling & Milling Machine
MABasic 400
Ø 35 X 55 mm Core Drilling
MABasic 850
Ø 75 X 110 mm Core Drilling
MAB 825
Ø 100 mm Core Drilling & M30 Tapping
MAB 845
Swivel Base Equipped Ø 100 mm Core Drilling & M30 Tapping
MAB 1300
Ø 130 mm Core Drilling & M42 Tapping
MAB 465
Ø 50 X 55 mm Drilling & M16 Tapping
AutoMAB 350
Ø 35 Fully Automatic Magnetic Drilling Machine
AutoMAB 450
Ø 45 Fully Automatic Magnetic Drilling Machine
MAB 825 V / MAB 845 V
Ø 60 mm Automatic / Ø 100 mm Manual Drilling
MAB 1300 V
Ø 60 mm Automatic / Ø 130 mm Manual Drilling
MAB 155PRO
